Cat Pumps 5CP Plunger Pump – 5CP5120
Material: Brass
Flow: 5.0 gpm / 19 lpm
Pressure: 100 – 3000 psi / 6.9 – 207 bar
Speed: 1415 rpm
Inlet Pressure Range: -2.5–60 psi / -0.2–4 bar
Max. medium temp.: 160°F / 71°C
Read more..
Large own stock
Outstanding service
Fast delivery (1-2 days)
Thé Cat Pumps-dealer since 1978
Product description
Cat Pumps 5cp5120
The Cat Pumps 5CP5120 is an industrial piston pump that excels in reliability and versatility. With a robust brass construction, a high flow rate and a wide pressure range, this pump is perfect for demanding applications. Whether you work in cleaning, production processes or other high-pressure applications, the 5CP5120 delivers the performance you need.
5CP5120 specifications
- Material: Brass
- Flow: 19 liters per minute
- Pressure range: 6.9 to 207 bar
- Speed: 1415 rpm
- Inlet pressure: -0.2 to 4 bar
- Maximum media temperature: 71°C
The Cat Pumps 5CP5120 is specially designed for reliability and versatility in demanding conditions. The triplex design delivers optimum efficiency, long life and consistent performance, making this pump suitable for intensive use.
The direct-drive option allows the pump to be installed in a compact manner, for example directly coupled to an electric motor with a NEMA or IEC frame or to a hydraulic motor with a bell housing and flexible coupling. This makes the pump easy to adapt to different applications.
The Cat Pumps 5CP5120 is equipped with NBR seals as standard, which are suitable for most situations. For specific requirements, such as higher temperatures or chemical compatibility, alternative sealing materials are also available.
| TYPE | DESCRIPTION | MAX. TEMP. | SUFFIX |
| NBR | Medium Nitrile (Buna-N) seals and O-Rings | 160°F (71°C) | - |
| FPM | Fluorocarbon (Viton®) seals and O-Rings, chemical resistance | 180°F (82°C) | .0110 |
| EPDM | Ethylene Propylene Diene Monomer seals and O-Rings | 160°F (71°C) | .0220 |
| HT | High-temperature high pressure seals | 180°F (88°C) | .3000 |
| STHT | High-temperature high pressure seals, special Teflon® low-pressure seals, NBR O-Rings | 190°F (88°C) | .3400 |
| High-temperature high pressure seals, special Teflon® low-pressure seals, FPM O-Rings | 190°F (88°C) | .3410 | |
| PTFE | Pure Polytetrafluoroethylene (Teflon®) Seals and Buna-N O-Rings | 190°F (88°C) | .0700 |
| Pure Polytetrafluoroethylene (Teflon®) Seals and FPM O-Rings | 200°F (93°C) | .0710 | |
| IPFE | I-Perfluoroelastomer (Teflon®) Seals and Isolast O-Rings | 200°F (93°C) | .0770 |
| ST4 | Special blend PTFE high and low pressure seals, Buna-N O-Rings | 190°F (88°C) | .4400 |
| Special blend PTFE high and low pressure seals, FPM O-Rings | 200°F (93°C) | .4410 | |
| NBRS | Buna-N silicone free seals and O-Rings | 160°F (71°C) | .6000 |
| FPM = Fluorocarbon, EPDM = Ethylene Propylene Diene Monomer, HT = High Temp (EPDM Alternative), STHT = Special PTFE High Temperature, PTFE = Pure Polytetrafluoroethylene, IPFE = I-Perfluoroelastomer, ST4 = Special PTFE 4, NBR = Medium Nitrile (Buna-N), NBRS = Buna-N silicon free seals and O-Rings. Viton® and Teflon® are registered trademarks of DuPont Dow Elastomers. | |||
Questions about Cat Pumps 5CP5120
At Pijttersen we have a team of specialists with years of experience in high-pressure technology. We are happy to help you with advice about the Cat Pumps 5CP5120 or other products. Do you have questions or would you like more information? Please contact us.
Documents
Cat Pumps Datasheet - Models 5CP5120, 5CP5120CSS - Pijttersen
Cat Pumps Service Manual - CP Plunger Pump - Pijttersen
Cat Pumps - Installation guidelines for high-pressure pumps - Pijttersen
Cat Pumps - Warnings and cautions for HP-pumps - Pijttersen
