Cat Pumps 5CP Plunger Pump – 5CP2150W
Material: Brass
Flow: 5.0 gpm / 19 lpm
Pressure: 100 – 2000 psi / 6.9 – 138 bar
Speed: 1725 rpm
Inlet Pressure Range: Flooded to 60 psi / Flooded to 4.1 bar
Max. medium temp.: 160°F / 71°C
Read more..
Large own stock
Outstanding service
Fast delivery (1-2 days)
Thé Cat Pumps-dealer since 1978
Product description
Cat Pumps 5CP2150W
The Cat Pumps 5CP2150W is manufactured from high-quality materials, including chrome-plated brass. With a flow rate of 15.5 liters per minute and a pressure range of 7 to 140 bar, this pump can meet the demands of various industrial processes. The 1450 rpm speed and maximum media temperature of 71°C make this pump suitable for a wide range of operating conditions.
Thanks to the user-friendly design with plug-in seal cases and interchangeable valve assemblies, the 5CP2150 is easy and quick to maintain, minimizing downtime and maximizing the efficiency of your processes.
Specifications Cat Pumps 5CP2150W
Material: Brass
Flow: 15.5 litres per minute
Pressure range: 7-140 bar
Speed: 1450 rpm
Inlet pressure: -0.35 to 4.1 bar
Max. Medium Temperature: 71°C
Additional information
This pump is equipped with NBR seals and O-rings as standard and is available in the following versions. The pump can be equipped with alternative seals, depending on the chemical composition of the medium to be pumped or the working temperature.
| TYPE | DESCRIPTION | MAX. TEMP. | SUFFIX |
| NBR | Medium Nitrile (Buna-N) seals and O-Rings | 160°F (71°C) | - |
| FPM | Fluorocarbon (Viton®) seals and O-Rings, chemical resistance | 180°F (82°C) | .0110 |
| EPDM | Ethylene Propylene Diene Monomer seals and O-Rings | 160°F (71°C) | .0220 |
| HT | High-temperature high pressure seals | 180°F (88°C) | .3000 |
| STHT | High-temperature high pressure seals, special Teflon® low-pressure seals, NBR O-Rings | 190°F (88°C) | .3400 |
| High-temperature high pressure seals, special Teflon® low-pressure seals, FPM O-Rings | 190°F (88°C) | .3410 | |
| PTFE | Pure Polytetrafluoroethylene (Teflon®) Seals and Buna-N O-Rings | 190°F (88°C) | .0700 |
| Pure Polytetrafluoroethylene (Teflon®) Seals and FPM O-Rings | 200°F (93°C) | .0710 | |
| IPFE | I-Perfluoroelastomer (Teflon®) Seals and Isolast O-Rings | 200°F (93°C) | .0770 |
| ST4 | Special blend PTFE high and low pressure seals, Buna-N O-Rings | 190°F (88°C) | .4400 |
| Special blend PTFE high and low pressure seals, FPM O-Rings | 200°F (93°C) | .4410 | |
| NBRS | Buna-N silicone free seals and O-Rings | 160°F (71°C) | .6000 |
| FPM = Fluorocarbon, EPDM = Ethylene Propylene Diene Monomer, HT = High Temp (EPDM Alternative), STHT = Special PTFE High Temperature, PTFE = Pure Polytetrafluoroethylene, IPFE = I-Perfluoroelastomer, ST4 = Special PTFE 4, NBR = Medium Nitrile (Buna-N), NBRS = Buna-N silicon free seals and O-Rings. Viton® and Teflon® are registered trademarks of DuPont Dow Elastomers. | |||
Documents
Cat Pumps Datasheet - Models 5CP2120W, 5CP2140WCS, 5CP2150W, 5CP2120B, 5CP2140BCS, 5CP2150B - Pijttersen
Cat Pumps Service Manual - CP Plunger Pump - Pijttersen
Cat Pumps - Installation guidelines for high-pressure pumps - Pijttersen
Cat Pumps - Warnings and cautions for HP-pumps - Pijttersen
