Cat Pumps 3 Frame Plunger Pump - 230
Material: Brass
Flow: 2.3 gpm / 8.7 lpm
Pressure: 100 – 1500 psi / 6.9 – 103 bar
Speed: 1725 rpm
Inlet Pressure Range: Flooded to 60 psi / Flooded to 4.1 bar
Max. medium temp.: 160°F / 71°C
Read more..
Large own stock
Outstanding service
Fast delivery (1-2 days)
Thé Cat Pumps-dealer since 1978
Product description
Cat Pumps 3 Frame Piston Pump 230
The Cat Pumps 3 Frame Piston Pump 230 is designed for optimum performance and reliability in demanding applications. With its robust brass construction, this pump offers excellent corrosion resistance and durability, ensuring long life and reduced maintenance.
Key Features:
- Excellent Efficiency: With a flow rate of 8.7 litres per minute and a pressure range of 6.9 to 103 bar, the pump delivers consistent and reliable performance for a variety of applications.
- Reliable Performance: The 1725 rpm speed ensures stable operation even under heavy use, while the inlet pressure range of 0.1 to 4.1 bar provides flexible application.
- Temperature Resistance: Suitable for media up to a maximum temperature of 71°C, making the pump ideal for a wide range of industrial and commercial applications.
- Durable Construction: The brass housing offers exceptional resistance to wear and corrosion, resulting in longer life and lower maintenance costs.
Specifications Cat Pumps 3 frame plunger pump 230
Material: Brass
Flow: 8.7 lpm
Pressure range: 6.9 – 103 bar
Speed: 1725 rpm
Inlet pressure: 0.1 – 4.1 bar
Max. Medium Temp.: 71°C
This is a Cat Pumps triplex plunger pump equipped with a brass pump head with stainless steel valves and solid ceramic plungers. This pump is equipped with NBR seals and O-rings as standard and is available in the following versions. The pump can be equipped with alternative seals, depending on the chemical composition of the medium to be pumped or the working temperature.
| TYPE | DESCRIPTION | MAX. TEMP. | SUFFIX |
| NBR | Medium Nitrile (Buna-N) seals and O-Rings | 160°F (71°C) | - |
| FPM | Fluorocarbon (Viton®) seals and O-Rings, chemical resistance | 180°F (82°C) | .0110 |
| EPDM | Ethylene Propylene Diene Monomer seals and O-Rings | 160°F (71°C) | .0220 |
| HT | High-temperature high pressure seals | 180°F (88°C) | .3000 |
| STHT | High-temperature high pressure seals, special Teflon® low-pressure seals, NBR O-Rings | 190°F (88°C) | .3400 |
| High-temperature high pressure seals, special Teflon® low-pressure seals, FPM O-Rings | 190°F (88°C) | .3410 | |
| PTFE | Pure Polytetrafluoroethylene (Teflon®) Seals and Buna-N O-Rings | 190°F (88°C) | .0700 |
| Pure Polytetrafluoroethylene (Teflon®) Seals and FPM O-Rings | 200°F (93°C) | .0710 | |
| IPFE | I-Perfluoroelastomer (Teflon®) Seals and Isolast O-Rings | 200°F (93°C) | .0770 |
| ST4 | Special blend PTFE high and low pressure seals, Buna-N O-Rings | 190°F (88°C) | .4400 |
| Special blend PTFE high and low pressure seals, FPM O-Rings | 200°F (93°C) | .4410 | |
| NBRS | Buna-N silicone free seals and O-Rings | 160°F (71°C) | .6000 |
| FPM = Fluorocarbon, EPDM = Ethylene Propylene Diene Monomer, HT = High Temp (EPDM Alternative), STHT = Special PTFE High Temperature, PTFE = Pure Polytetrafluoroethylene, IPFE = I-Perfluoroelastomer, ST4 = Special PTFE 4, NBR = Medium Nitrile (Buna-N), NBRS = Buna-N silicon free seals and O-Rings. Viton® and Teflon® are registered trademarks of DuPont Dow Elastomers. | |||
