Cat Pumps 15 Frame Plunger Pump - 1530C

Cat Pumps 15 Frame Plunger Pump 1530C

The Cat Pumps 15 Frame Plunger Pump 1530C is a reliable and powerful pump designed for demanding industrial applications. With rugged brass construction and advanced features, this pump offers exceptional performance and long life.

Specifications Cat pumps 1530C:

Material: Brass, Flushed
Flow rate: 59 liters per minute
Pressure range: 6.9 – 103 bar
Speed: 1450 rotations per minute
Inlet pressure: 0.1 – 4.8 bar
Maximum medium temperature: 60°C

Most important features:

• Triplex design: Provides continuous forward fluid flow and minimal pulsation, resulting in smooth and stable operation.
• Flushed system: This system ensures that all internal components are effectively flushed and cooled, which extends the life of the pump and increases reliability.
• High Quality Brass Construction: Provides excellent corrosion resistance and durability, even in harsh industrial environments.
• Wide pressure range: Suitable for various applications thanks to the pressure range from 6.9 to 103 bar.
• High speed capacity: With a maximum rotation speed of 1450 RPM, this pump delivers consistent and efficient performance.
• Flexible inlet pressure: Can operate with inlet pressure ranging from 0.1 to 4.8 bar, providing flexibility for different installation configurations.
• Temperature resistance: Can pump media up to a maximum temperature of 60°C, ensuring versatility in use.

Applications:

The Cat Pumps 1530C is ideal for a wide range of industrial applications such as high-pressure cleaning, waterjet cutting, and other applications where high performance and reliability are required.

Personal advice about Cat Pumps

Do you have questions or would you like to know more about how this pump can meet your specific needs? Our dedicated customer service team is ready to assist you. Don't hesitate to contact us and we will be happy to help you.

Documents Cat Pumps 1530C

Cat Pumps Datasheet - Models 1530, 1530C, 1531 - Pijttersen

Cat Pumps Service Manual - 15-25PFR Plunger Pumps - Pijttersen

Cat Pumps - Installation guidelines for high-pressure pumps - Pijttersen

Cat Pumps - Warnings and cautions for HP-pumps - Pijttersen
