Cat pumps 67 Frame Plunger Pump 6767
Discover the power and reliability of the Cat Pumps 67 Frame Plunger Pump 6767. With a rotational speed of 520 RPM, a capacity of 227 liters per minute and a maximum working pressure of 83 bar, this pump is the ideal choice for demanding applications. Read more..
Large own stock
Outstanding service
Fast delivery (1-2 days)
Thé Cat Pumps-dealer since 1978
Product description
Cat Pumps 67 Frame Plunger Pump 6767
Discover the power and reliability of the Cat Pumps 67 Frame Plunger Pump 6767. With a rotational speed of 520 RPM, a capacity of 227 liters per minute and a maximum working pressure of 83 bar, this pump is the ideal choice for demanding applications.
Suitable for intensive use and long-term operation
The Cat Pumps 67 Frame Piston Pump 6767 is built to the highest quality standards and designed for reliable performance. With its sturdy construction and durable materials, this pump can effortlessly handle heavy use and long-term operation.
Large capacity
With a capacity of 227 liters per minute, the Cat Pumps 67 Frame Piston Pump 6767 is capable of pumping large volumes of liquid in a short period of time. This makes it ideal for applications where speed and efficiency are essential. Whether you want to clean a large area or require high pressure for your work, this pump can handle it.
Maximum working pressure
With a maximum working pressure of 83 bar, the Cat Pumps 67 Frame Plunger Pump 6767 is capable of tackling even the most demanding tasks. This high pressure ensures thorough cleaning and optimum performance, even in the toughest conditions. Whether you want to remove stubborn dirt or prepare a surface for painting, this pump provides the power you need to get the job done.
TYPE | OMSCHRIJVING | MAX. TEMP. | SUFFIX |
|
NBR | Medium nitril (Buna-N) afdichtingen en O-ringen | 71°C | - |
|
FPM | Fluorocarbon (Viton®) afdichtingen en O-ringen, chemische bestendigheid | 82°C | .0110 |
|
EPDM | Ethyleen Propyleen Dieen Monomeer afdichtingen en O-ringen | 71°C | .0220 |
|
HT | Hoge-temperatuur-hogedrukafdichtingen | 88°C | .3000 |
|
STHT | Hoge-temperatuur-hogedrukafdichtingen, speciale Teflon®-lagedrukafdichtingen, NBR O-ringen | 88°C | .3400 |
|
| Hoge-temperatuur-hogedrukafdichtingen, speciale Teflon®-lagedrukafdichtingen, FPM O-ringen | 88°C | .3410 |
|
PTFE | Zuiver polytetrafluorethyleen (Teflon®) afdichtingen en Buna-N O-ringen | 88°C | .0700 |
|
| Zuiver polytetrafluorethyleen (Teflon®) afdichtingen en FPM O-ringen | 93°C | .0710 |
|
IPFE | I-perfluorelastomeer (Teflon®) afdichtingen en Isolast O-ringen | 93°C | .0770 |
|
ST4 | Speciale mix PTFE hoge- en lagedrukafdichtingen, Buna-N O-ringen | 88°C | .4400 |
|
| Speciale mix PTFE hoge- en lagedrukafdichtingen, FPM O-ringen | 93°C | .4410 |
|
NBRS | Buna-N siliconenvrije afdichtingen en O-ringen | 71°C | .6000 |
|
|
|
|
|
|
FPM = Fluorocarbon, EPDM = Ethyleen Propyleen Dieen Monomeer, HT = Hoge temperatuur (EPDM alternatief), STHT = Speciale PTFE Hoge temperatuur, PTFE = Zuiver Polytetrafluorethyleen, IPFE = I-Perfluorelastomeer, ST4 = Speciaal PTFE 4, NBR = Medium Nitril (Buna-N), NBRS = Buna-N siliconenvrije afdichtingen en O-ringen. Viton® en Teflon® zijn geregistreerde handelsmerken van DuPont Dow Elastomers. | ||||
Documenten Cat Pumps 67 Frame Plunjerpomp 6767
Cat Pumps Datasheet - Cat Pumps 67 Frame Plunjerpomp 6767
Cat Pumps Service Manual - Cat Pumps 67 Frame Plunjerpomp 6767
Cat Pumps - Installatie richtlijnen voor hogedrukpompen - Pijttersen
Cat Pumps - Veiligheidsinstructies voor hogedrukpompen - Pijttersen
Specifications
Cat pumps 67 Frame Plunger Pump 6767
